| Input supply |
230 V. Ac, 50 Hz |
| Size |
8.5"X 10.75" X 3.5" (LxWxH) |
| Weight |
2.5 kg. (approx.) |
| For IFT |
| Modes |
2P, 4P, 4PV, 4PV 45, 4PV 90 |
| Carrier Frequency |
2K Hz, 4k Hz. Base: 0-150Hz, Sweep: 0-100Hz
|
| Medium Frequency |
: 4 K Hz, 2 K Hz |
| Carrier Frequency |
: 0-50 Hz, 50-80 Hz, 80-100 Hz, 100-120 Hz,
120-150 Hz |
| Output Current : 0-100 mA, |
|
| Timer |
: 1 To 99 Minutes Programable |
| Buzzer |
Audio Buzzer at the End of Treatment
Time |
| For Ultrasound
|
| Frequency |
1 MHZ |
| Output Mode |
Continuous & Pulsed (1:1, 1:4, 1:7, 1:10) |
| Intensity |
Continuous Mode 0 to 3.5 watts/cm |
| Pulsed Mode |
1.1 TO 2.0 Watts / Cm |
| Timer |
1 to 99 Minutes Programmable |
| Buzzer |
Audio Buzzer at The End of Treatment Time |
